Introduction to Pull Stud
Pull studs, also called retention knobs, are used for connecting tool holders to the machines drawbar. Available with or without through coolant and in an O-Ring style to prevent coolant leakage.
Mainly used for screwing in large taper tool holders, workpiece supports and pallets. In combination with SSK clamps, they are used to suck in and eject the above mentioned machine elements.
The dimensions, surface quality, hardness and strength values of Pull studs comply with the values specified in DIN, ANSI, ISO, MAS and JIS standards.
pull stud description
1.Material: 20CrMnTi
2Head hardness: HRC55-58
3. Threads and other hardness are low, 35±5HRC (protection handle thread, core hardness can withstand impact)
3. Accuracy: 0.01 high precision
4.Tight and stable, special anti-rust material, overall carburizing treatment, improves wear resistance and tensile strength, and the overall performance is better.
Benefits of Pull studs
Our Pulls are manufactured from the finest steel to ensure minimal wear and ensure a strong inner core that will resist the normal wear and tear caused by CNC machines; most commonly, a retaining knob is added to the tail of the taper to allow for levering on the outside Clamp it and pull it axially into the spindle nose,great for runout accuracy, balance repeatability, and machine tool drawbar consistency; higher quality retaining knobs will better resist wear and deformation, and they will also be more accurately positioned on the centerline of the tool holder, another common The option is a bolt built into the spindle that can be activated to tighten or loosen the tool holder
Pull Stud working principle
One end of the Pull Stud is connected to the machine tool bayonet, and the other end is connected to the tool holder. The d part is stuck in according to the degree of the machine tool bayonet. The g part has threads and the tool holder is tightened. The axial force transmitted through the tie rod and the tie rod joint and Pull Stud , to tighten the tool handle. When changing tools, it is required to loosen the tool handle. When Pull Stud is installed on the spindle of an ordinary machine tool or CNC machine tool, the arc joint of the rod body is connected to the front end of the tie rod structure, and the screw joint of Pull Stud extends into the spindle axis hole. The inner screw holes of the tool holder are matched and connected. The tool holder can be used on ordinary machine tools and CNC machine tools, so that the tool holder can be used not only on machining centers, but also on ordinary machine tools and CNC machine tools, which improves the tool holder. The versatility reduces production costs.
product Feature
Strict quality inspection, better quality, high
toughness and tensile strength
Through-hole drainage, threads and other parts have
low hardness: 55-58HRC, protection handle thread,
core hardness can resist impact.
Strong tensile strength, carburizing and quenching,anti-corrosion and anti-rust
The handle is harder than ordinary，The rivets are increased by 3-4 degrees,Stronger wear resistance, rust resistance and tensile strength.
Preferred materials, exquisite workmanship，high precision and stable performance
Made of high-quality steel, it greatly improves the service life and wear resistance of the rivet claws, and ensures precise and stable clamping.
Adequate inventory and complete specifications
This product is available in a variety of specifications to meet different processing conditions and processing equipment requirements.
Pull Stud Application
Detached（Released）State
Released Air Pressure：ON
Lock Air Pressure：OFF
Provide release air pressure，allowing for pulling in and out the pull bolt
Workplece Setting（Before Connected）
Released Air Pressure：ON
Lock Air Pressure：OFF
Insert the pull bolt
Connected（Locked）State
Release Air Pressure：OFF
Lock Air Pressure：ON
The pull bolt is pulled in buy theplston
and steel balls with lock air+spring force to complete the locking operation
